Focused Ion Beam SEM and Cross-Section Analysis (FIB-SEM)
Characterise buried interfaces and layer thickness, site-specific defects, pores, and microstructure, and three-dimensional or chemical distribution when serial imaging or SIMS is added using a scope agreed around your sample…
- Price
- from£240 per sample, excl. VAT
- Turnaround
- 14 working days Preparation and scope dependent
- Available platforms
- Thermo Fisher Helios Hydra 5+ZEISS Crossbeam 550TESCAN AMBER X 2Strata 400S FEI Thermo Fisher Helios 5 CX
- Typical outputs
- Cross-section imagesMilling and preparation recordOptional 3D volume, TEM lamella, atom-probe needle, or ion mapsMethod-specific images
Why this test
What FIB-SEM can help you understand
Focused Ion Beam SEM and Cross-Section Analysis is selected when the project needs defensible information on buried interfaces and layer thickness, site-specific defects, pores, and microstructure, or three-dimensional…
Site-specific defects, pores, and microstructure
lift-out TEM lamella
Three-dimensional or chemical distribution when serial imaging or SIMS…
serial section tomography
Choose the scope
Start from the question, not the instrument
The measurement mode, preparation route and reporting depth depend on what you need to learn from the sample.
Cross-section and polish
buried interfaces and layer thickness
- Best used when
- buried interfaces and layer thickness
- Typical result
- Cross-section images
- Preparation note
- Exact mass and any drying or dispersion step are confirmed after technical review.
Lift-out TEM lamella
site-specific defects, pores, and microstructure
- Best used when
- site-specific defects, pores, and microstructure
- Typical result
- Milling and preparation record
- Preparation note
- State the substrate, nominal thickness and whether sectioning or mounting is permitted.
Serial section tomography
three-dimensional or chemical distribution when serial imaging or SIMS is added
- Best used when
- three-dimensional or chemical distribution when serial imaging or SIMS is added
- Typical result
- Optional 3D volume, TEM lamella, atom-probe needle, or ion maps
- Preparation note
- Confirm power, connections, operating state, access restrictions and permitted disassembly.
Common outputs
A result package matched to the decision you need to make
Fields, measurement conditions, processing and file formats are confirmed before work begins.
Cross-section images reported with the agreed units, sample reference and measurement conditions.
Milling and preparation record supplied in a labelled format suitable for direct sample or condition comparison.
Optional 3D volume, TEM lamella, atom-probe needle, or ion maps provided with the processing basis and quality checks agreed during technical review.
Method-specific images included when selected in the confirmed reporting scope.
Sample requirements
What to send
Provide representative, clearly labelled samples and identify the region, feature or comparison that matters.
| Suitable sample or input | Submission requirement | Planning note |
|---|---|---|
| Powder / particles | Provide a dry, homogeneous and clearly labelled sample in a sealed container. | Exact mass and any drying or dispersion step are confirmed after technical review. |
| Film / coating | Provide the coated substrate or a flat film with the test surface and coating side clearly marked. | State the substrate, nominal thickness and whether sectioning or mounting is permitted. |
| Device / assembly | Provide a complete labelled device or assembly with drawings, interfaces and operating limits. | Confirm power, connections, operating state, access restrictions and permitted disassembly. |
| Solid / component | Provide a clean, stable and clearly labelled specimen with the target face or region identified. | Confirm dimensions, cutting permission and whether the original geometry must be preserved. |
Region of interest: include a marked image, sketch or reference when the target feature is localised.
Handling: declare hazardous, magnetic, volatile, moisture-sensitive, beam-sensitive or temperature-controlled material before dispatch.
Questions and answers
Common planning decisions
Short answers to issues that can change preparation, scope or interpretation.
What should I send for Focused Ion Beam SEM and Cross-Section Analysis?
Provide powder / particles, film / coating, device / assembly, solid / component as applicable. Exact quantity, dimensions and preparation are confirmed during technical review.
Which analysis option should I choose?
Choose the mode around the decision you need to make. For buried interfaces and layer thickness, start with cross-section and polish; add lift-out TEM lamella when comparison or quantification is required.
How long will the test take?
Typical turnaround is 14 working days after sample acceptance and method confirmation.
What can limit the result?
Ion implantation, curtaining, redeposition, and amorphisation can occur. The method is local and destructive.
Configure the service
Send the information needed to scope FIB-SEM correctly
- Sample form, material, dimensions and quantity
- Feature or decision the result must address
- Marked region of interest where relevant
- Required comparison, output and reporting depth
